Ubiquiti UXG-Pro UniFi Gateway Pro

$499.00

  • 10G multi-WAN independent gateway with UniFi Power Backup support designed to protect large-scale networks.
  • Managed by a CloudKey, Official UniFi Hosting, or UniFi Network Server
  • 3.5+ Gbps routing with IDS/IPS
  • (1) 10G SFP+* and (1) GbE WAN port
  • (1) 10G SFP+* and (1) GbE LAN port
  • UniFi Power Backup ready
  • *Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.

✅42 in stock

SKU: UXG-PRO-US Category:

Description

Mechanical
Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
Weight 3.4 kg (7.5 lb)
Enclosure material Front panel: aluminum CNC
Top cover/base: SGCC steel
Hardware
Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz
Memory information 2 GB DDR4
Management interface Ethernet
Networking interface LAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ portWAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
IDS/IPS throughput 3.5 Gbps*
*Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation.
Power method US:
(1) Universal AC input, 125V AC, 2.7A Max., 60 Hz
(1) RPS DC input, 11.5V DC, 2.87AWorldwide:
(1) Universal AC input, 200–240V AC, 1.7A Max., 50/60 Hz
(1) RPS DC input, 11.5V DC, 2.87A
Power supply AC/DC, internal, 50W
Max. power consumption 30W
ESD/EMP protection Air: ± 15kV, contact: ± 8kV
LCM display (1) 1.3″ touchscreen
Button Factory reset
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting
Next-generation security Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced networking License-free SD-WAN*
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport* and Identity Enterprise VPN**
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support*When paired with a CloudKey or Official UniFi Hosting.
**When paired with a CloudKey.
LEDs
Ethernet Green/amber
SFP+ White/green
AC outlet/ RPS Blue
Software
Management application UniFi Network: Version 5.14.11 and later
