Specifications UVC-G6-INS-W
| Dimensions | 81.7 x 50.1 x 57.2 mm (3.2 x 2 x 2.3″) |
| Weight | 180 g (6.3 oz) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Weatherproofing | IPX5 |
| Resistance | IK04 |
| Pole mount diameter | Min. 1.5″ (38 mm) |
| Cable length | 2 m (6.6 ft) |
| Cable diameter | 3 mm (0.1″) |
| Cable jacket material | Thermoplastic elastomer |
| Cable connector type | USB Type-C to USB Type-C |
| Optics | |
| Sensor | 1/1.8” 8MP |
| Lens | Fixed focal length |
| View angle | H: 109.9°, V: 56.7°, D: 134.1° |
| Night mode | Built-in IR LED illumination and IR cut lter |
| IR distance | 6 m (20 ft) |
| Video | |
| Resolution | 8MP 3840 x 2160 (16:9) |
| Max. frame rate | 30 FPS |
| Image settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
| System | |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Networking interface | 802.11 a/b/g/n/ac WiFi Bluetooth |
| Max. power consumption | 7W |
| Power method | 5V, 2A USB power adapter (Included) Instant PoE to USB adapter (Not included) |
| Supported voltage range | 5V DC |
| LED | R/G/B/W |
| Button | Factory reset |
| Mounting | Desktop, wall, pole, angle mount (Included) |
| Ambient operating temperature | -20 to 40° C (-4 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes (Can be disabled) |
| Speaker | Yes |
| 2-way audio | Yes, with noise cancellation |
| Software | |
| Web application | UniFi Protect |
| Mobile app | UniFi Protect iOS™ and Android™ |
