Description
Overview
Dimensions
95.95 x 65 x 12.5 mm
(3.8 x 2.6 x 0.5″)
Uplink
(2) GbE RJ45 ports
WiFi
WiFi Standards
WiFi 5
Mechanical
Weight
89 g (3.1 oz)
Enclosure Material
Polycarbonate
Features
WAN
WiFi
✓
Ethernet
✓
VPN Client
OpenVPN
✓
WireGuard
✓
Port Forwarding
✓
Firewall
✓
Networking
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
802.11n
6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
Hardware
Management
Ethernet
Bluetooth
Antennas
Type
(2) Embedded WiFi antennas
Max. TX Power
2.4G: 13 dBm
5G: 13 dBm
WiFi MIMO
2 x 2
Max. Power Consumption
5W
Power Method
USB-C
Power Supply
USB-C, 5V/2A
(Adapter not included)
Display
1.14″ status display
Buttons
(1) Factory-reset
Ambient Operating Temperature
-10 to 40 °C (-40 to 104 °F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Certifications
CE, FCC, IC
