Description
Overview
Dimensions
Ø48 x 107.5 mm (Ø1.9 x 4.2″)
IR Night Vision
6 m (20 ft)
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
2K
Field of View
H: 102.4°, V: 54.9°, D: 120.6°
Audio
Microphone
Weatherproofing
IPX4 (While Covered)
Tamper Resistance
IK04
Mounting
Desktop, Wall, pole mount, hard-ceiling (Included) In-ceiling mount, pendant, Pro mount (Optional)
UniFi Application Suite
Protect
Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
Max. Frame Rate
30 FPS
Resolution
4MP 2688 x 1512 (16:9)
Optics
Sensor
5MP CMOS
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
4W
Supported Voltage Range
37—57V DC
Power Method
PoE
Processor
Dual-core Arm® Cortex®-A7 based chip
Pole Mount Diameter
1–1.5″ (25–38 mm)
Weight
170 g (6 oz)
Enclosure Material
Polycarbonate
Mount Material
Polycarbonate
Button
(1) Factory-reset
Ambient Operating Temperature
-20 to 40° C (-4 to 104° F)
Ambient Operating Humidity
0 to 90% noncondensing
Certifications
CE, FCC, IC
