Description
Overview
Dimensions
Device: 160.6 x 51.7 x 35.1 mm (6.3 x 2 x 1.4″) Wall mount: 159.3 x 50.3 x 17.5 mm (6.3 x 1.9 x 0.7″) Wedge: 161.1 x 52.1 x 25.7 mm (6.3 x 2.1 x 1″) On-wall mount: 161.1 x 52.1 x 25.75 mm (6.3 x 2.1 x 1″)
IR Night Vision
6 m (20 ft)
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
FHD
Field of View
Main camera: H: 138°, V: 114°, D: 155° (LDC On) Main camera: H: 160°, V: 117°, D: 160° (LDC Off) Package camera: H: 97.5°, V: 79.4°, D: 118.2°
Audio
Two-way audio
Weatherproofing
IPX4 (While Covered)
Mounting
Wall, wedge (Included) Gang box, junction box (Optional)
UniFi Application Suite
Protect
Performance
Networking Interface
GbE RJ45 port
Video
Max. Frame Rate
30 FPS
Resolution
Main camera: 2MP 1600 x 1200 (4:3) Package camera: 2MP 1600 x 1200 (4:3)
Optics
Sensor
Main camera: 5MP CMOS Package camera: 8MP CMOS
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
7W
Supported Voltage Range
37—57V DC
Power Method
PoE
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
Device: 264 g (9.3 oz) Wall mount: 56 g (2 oz) Wedge: 33 g (1.2 oz) On-wall mount: 53 g (1.9 oz)
Enclosure Material
Polycarbonate, aluminum alloy
Mount Material
Polycarbonate, aluminum alloy
Button
Ring Button Factory Reset
Ambient Operating Temperature
-30 to 40º C (-22 to 104º F)
Ambient Operating Humidity
0 to 90% noncondensing
Certifications
CE, FCC, IC
Chime
Dimensions
Device: Ø62 x 54 mm (Ø2.5 x 2.1″) In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5″) On-wall Mount: Ø62 x 20.2 mm (Ø2.5 x 0.8″)
Weight
Device: 158 g (5.6 oz) In-wall mount: 91 g (3.2 oz) On-wall mount: 28 g (1 oz)
Enclosure Material
Polycarbonate, aluminum alloy
Mounting Material
Polycarbonate, zinc alloy
Networking Interface
10/100 MbE port
Power Method
PoE
Supported Voltage Range
44—57V DC
Max. Power Consumption
3W
Speaker
Yes
Buzzer
Yes
Buttons
(1) Factory-reset
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
LEDs
R/G/B/W
Software
Mobile app
UniFi Protect iOS™ and Android™
