Description
Features
- PoE Injector
- IEEE 802.3at/af High Power Gigabit Midspan PoE Injector
- Up to 40W per Individual Port
- 1U Standard Rack Mount (19”)
- Configuration and status thru front panel RJ45 port or thru network
- Supports non standard (Passive) devices
- Accepts AC or DC input
- Remotely Power Multiple Equipment thru CAT5 Cable up to 100m
Applications
- Wireless Access Points and Client Devices
- IP Phone and Security Camera Systems
- Power network devices from a central network room
Description
The TP-MS616 rack mount 16-port mid-span PoE Injector power source efficiently powers up to 16 devices from a centralized location, such as an operations room. This advanced device supports IEEE802.3at/af standards and Gigabit Ethernet, ensuring high-speed data transmission and reliable performance for demanding network environments.
Advanced Port Management Furthermore, the TP-MS616 includes sophisticated PC software that allows you to configure individual ports and monitor port status through the RJ45 management port or network. This software enables you to easily enable or disable ports and configure them for Passive PoE or IEEE802.3at/af detection, providing exceptional flexibility and control over your network.
Efficient Power Delivery Moreover, the TP-MS616 delivers PoE DC voltage (55V) via pins 4,5 (V+) and 7,8 (V-), ensuring consistent and reliable power to connected devices. With autoranging capabilities, it seamlessly accepts AC inputs from 90VAC to 264VAC and supplies regulated DC output. This feature enhances its adaptability to various power environments, making it a versatile choice for diverse applications.
High-Powered and Safe Additionally, the TP-MS616 is designed to support high-powered devices, with a maximum power output of 576W per unit. Each output includes essential protection mechanisms, such as overload and short circuit protection, ensuring enhanced reliability and safety for all connected devices.
Compact, Easy Installation The TP-MS616 also boasts a compact 1U rack mount design that accommodates standard 19″ racks. Included brackets ensure quick and easy installation in any setup, making it ideal for both industrial and commercial environments. This user-friendly design simplifies the installation process, reducing setup time and effort.
