Description
| Mechanical | |
|---|---|
| Dimensions | 420 x 420 x 230 mm (16.5 x 16.5 x 9.1″) |
| Weight | 2.2 kg (4.9 lb) |
| Enclosure material | UV-stabilized plastic, powder-coated SPCC |
| Wind loading | 380 N at 200 km/h (85.4 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Mounting | Pole mount kit (Included) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
| Max. power consumption | 8.5W |
| Supported voltage range | 20—27V DC |
| Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
| ESD/EMP protection | Air/contact: ± 24 kV |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| Salt fog test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
| Vibration test | IEC 68-2-6 |
| Temperature shock test | IEC 68-2-14 |
| UV test | IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4 |
| Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5 |
| Ambient operating temperature | -40 to 70 C (-40 to 158 F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, RoHS |
| System | |
| Gain | 25 dBi |
| Channel sizes | PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz |
| Operating Frequency (MHz) | |
| Worldwide | 5150-5875 MHz |
| USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 |
5150-5250 MHz 5250-5350 MHz 5240-5725 MHz 5725-5850 MHz |
| Management Radio (MHz) | |
| Worldwide | 2412 – 2472 MHz |
| US/CA | 2412 – 2462 MHz |
Key Features
- High Performance: Achieve 450+ Mbps throughput with the PowerBeam PBE-5AC-Gen2, perfect for demanding network tasks.
- Extended Range: Designed for point-to-point communication with a link range of over 15 km.
- Advanced Design: Includes an integrated dish reflector for optimized signal transmission.
- Dedicated Management Radio: Separate WiFi management simplifies setup and diagnostics.
- Weather-Resistant: Built to withstand harsh environments, with wind survivability up to 125 mph.
FAQs
What is the maximum range of the PowerBeam PBE-5AC-Gen2?
The PowerBeam PBE-5AC-Gen2 supports a link range of up to 15+ km, ideal for long-distance connectivity.
Can this device handle high wind speeds?
What is the maximum range of the PowerBeam PBE-5AC-Gen2?
The PowerBeam PBE-5AC-Gen2 supports a link range of up to 15+ km, ideal for long-distance connectivity.
Can this device handle high wind speeds?
Yes, it can withstand wind speeds up to 125 mph.
What power supply is needed for this device?
It requires a 24V, 0.5A Gigabit PoE adapter, which is included in the package.
Does the PowerBeam PBE-5AC-Gen2 support spectral analysis?
Yes, it includes a dedicated spectral analysis radio for enhanced performance monitoring.
Is the device compatible with all routers?
It works seamlessly with routers supporting 5GHz frequency bands.
