Description
| Mechanical | |
|---|---|
| Dimensions | 747 x 525 x 347 mm (29.4 x 20.7 x 13.7″) |
| Weight | 3.2 kg (7.1 lb) |
| Enclosure material | Aluminum alloy, UV-stabilized polycarbonate |
| Mount material | UV-stabilized polycarbonate |
| Mount | Integrated pole mount (included) Pole compatibility: Ø35 to 60 mm (Ø1.4 to 2.4″) |
| Wind loading | 1100 N at 200 km/h (247.29 lbf at 125 mph) |
| Weatherproofing | IPX6 |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE 2-pair (4, 5+; 7, 8- ) |
| Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
| Supported voltage range | 22—27V DC |
| Max. power consumption | 9W |
| RF connections | Internal |
| LEDs | Power/Ethernet |
| Button | Factory reset |
| Ambient operating temperature | -40 to 55° C (-40 to 131° F) |
| Ambient operating humidity | 5 to 95% non-condensing |
| Certifications | FCC, IC, CE |
| Software | |
| Modes | PtMP CPE, PtP* *1.5.1 and later 1.5.x series firmware. |
| Services | SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog |
| Utilities | airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation |
| Auto distance adjustment | Yes |
| Auto power adjustment | Yes |
| Network | Bridge/Router* mode *Router mode is available in PtMP CPE mode only. |
| Security | Yes |
| Statical reporting | Yes |
| Management interface | Bluetooth management for easy setup over UISP App WEB UI |
| Minimum software requirements | Any modern web browser iOS™ or Android™ based smartphone |
| System | |
| Maximum throughput | 900+ Mbps* *FW version 2.3.0 and later. |
| Encryption | WPA2-PSK (AES) |
| Uplink/downlink ratio | 25/75, 33/67, 50/50 |
| RF | |
| Operating frequency* | 5.15 to 5.95 GHz *Depends on regulatory region. |
| Max. conducted TX power | 25 dBm |
| Channel bandwidth | 10/20/30/40/50/60/80/100 MHz* *FW version 2.3.0 and later. |
| Antenna gain | 29 dBi |
| Isolation | 20 dB |
| Beamwidth | HPOL: 3 dB: 5.5°, 6 dB: 7.5° VPOL: 3 dB: 5.5°, 6 dB: 7.5° Elevation: 3 dB: 5.5°, 6 dB: 7.5° |
| Electrical downtilt | 0° |
Key Features of LTU Extreme-Range
- Extreme Range Connectivity – Designed for long-distance wireless links with stable performance.
- Advanced LTU Technology – Proprietary chipset for superior efficiency and scalability compared to 802.11 protocols.
- Flexible Bandwidth Options – Supports 10/20/30/40/50 MHz channel widths for tailored network configurations.
- High Throughput – Delivers consistent, high-speed data transmission even in challenging environments.
- Rugged Build – Engineered for reliable performance in extreme weather conditions.
- Easy Management – Intuitive configuration via the LTU web-based management system.
How to Use LTU Extreme-Range
- Unbox and Inspect – Ensure all components, including the LTU device, mounting kit, and PoE adapter, are present.
- Mount the Device – Attach the LTU unit securely to a pole or surface using the provided hardware.
- Connect to Power – Use the included PoE adapter to power the device and link it to your network.
- Configure Settings – Access the LTU management system via a web browser to set up and optimize the device.
- Align the Signal – Fine-tune the alignment for maximum signal strength and link quality.
FAQs
1. Can it handle harsh weather?
Yes, it has a rugged design for extreme conditions.
2. What bandwidths are supported?
10/20/30/40/50 MHz channel widths.
3. What’s in the box?
LTU device, mounting kit, PoE adapter.
4. How is it powered?
With the included PoE adapter.
5. Can it do point-to-point or multipoint?
Yes, supports both configurations.
