(1) GbE RJ45 port
(8) 10G SFP+ ports
(2) Hot-swappable AC/DC PSU
Rack-mountable, 1UDescription
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 285.6 x 43.7 mm (17.4 x 11.2 x 1.7″) |
| Weight | 5 kg (10.9 lb) |
| Enclodure material | SGCC steel |
| Hardware | |
| System memory | 16 GB DDR4 RAM |
| On-board flash storage | 8 MB NOR 4 GB eMMC NAND |
| Management interface | (1) RJ45 CLI management port |
| Networking interface | (1) GbE RJ45 port (8) 10G SFP+ ports |
| Total non-blocking throughput | 80 Gbps |
| Switching capacity | 160 Gbps |
| Forwarding rate | 18 Mpps |
| Power method | (2) Hot-swappable AC/DC (Included) or DC/DC (Not included) PSU, 100W |
| Supported voltage range | AC/DC: 100–240V AC, 24V DC output DC/DC: 38–54V DC, 24V DC output |
| Max. power consumption | 100W |
| ESD/EMP protection | Air/contact: ± 24kV |
| LEDs | System: status Ethernet ports: link/activity SFP+ ports: link/activity |
| Button | Factory reset |
| Mounting | Yes, 1U |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
