(5) GbE RJ45 ports with 24V passive PoE
(1) SFP port
Fanless, thermal cooling
Desk, wall, and rack-mountable*Description
| Mechanical | |
|---|---|
| Dimensions | 229 x 136.5 x 31.1 mm (9 x 5.4 x 1.2″) |
| Weight | 730 g (1.6 lb) |
| Enclosure material | Metal |
| Hardware | |
| System memory | 1GB DDR3 RAM |
| On-board flash storage | 4GB eMMC 8MB SPI NOR |
| Management interface | (1) RJ45 serial port |
| Networking interface | (5) GbE RJ45 ports (1) 1G SFP port |
| PoE interface | (5) 24V Passive PoE ports (2-pair and 4-pair) |
| Power method | AC/DC power adapter, 24V, 2.5A (Included) |
| Power supply | AC/DC adapter, external, 60W |
| Supported voltage range | 16–30V DC |
| Max. power consumption | 16W (Excluding PoE output) |
| Max. PoE wattage per port | 24W (24V, 1A, 4-pair) 12W (24V, 0.5A, 2-pair) |
| LEDs | Ethernet ports: PoE, link/speed/activity SFP port: link/activity |
| Button | Factory reset |
| Mounting | Wall, rack* *With optional Rack Mount Kit, model ER-RMKIT. |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
