Description
| Mechanical | |
|---|---|
| Dimensions | 593 x 768 x 370 mm (23.4 x 30.2 x 14.6″) |
| Weight | 17.3 kg (38.1 lb) |
| Mounting | Pole mount kit (Included) |
| Wind loading | 770 N @ 200 km/h (170 lbf @ 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port (1) 10/100 MbE RJ45 port |
| Auxiliary port | (1) RJ-12, alignment tone port |
| Power method | Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 😎 |
| Power supply | 50V, 1.2A gigabit PoE adapter (Included) |
| Supported voltage range | 42–58V DC |
| Max. power consumption | 50W |
| Operating frequency | 24.05 – 24.25 GHz |
| Ambient operating temperature | -40 to 55° C (-40 to 131° F) |
| Certifications | CE, FCC, IC |
| System | |
| Max. throughput | 2 Gbps |
| Ma. range | 20+ km |
| Packets per second | 1+ million |
| Encryption | 128-bit AES |
| Uplink/Downlink ratio | Programmable in Half Duplex mode |
| RF | |
| GPS | GPS clock synchronization |
| EIRP | ~33 dBm (FCC/IC) ~20 dBm (CE) ~40 dBm (Other Regions) |
| Frequency accuracy | ±2.5 ppm without GPS synchronization ±0.2 ppm with GPS synchronization |
| Channel bandwidth | 100 MHz |
| Operating frequency | 24.05 – 24.25 GHz |
| Operating channels | 24.1 GHz, 24.2 GHz |
| Modulation | 256QAM 64QAM 16QAM QPSK MIMO QPSK SISO ¼x QPSK SISO |
| Gain TX RX |
33 dBi 40 dBi |
| Beamwidth | < 3.5° |
| Front-to-back ratio | 70 dB |
| Polarization | Dual-slant |
| Cross-polarity Iiolation | > 28 dB |
| LEDs | |
| System | (8) Status LEDs: Data port speed Data port link/activity Configuration port speed Configuration port link/activity GPS synchronization Modulation mode Master/slave RF status(1) Two-digit LED display calibrated in dBm |
Key Features:
- 2Gbps Throughput – Achieve reliable high-speed wireless connectivity for critical applications.
- 20km Range – Designed for long-distance point-to-point communication.
- Integrated Antennas – Built-in TX and RX antennas for enhanced signal reliability.
- Weatherproof Design – Operates seamlessly in harsh environmental conditions.
- Low Latency – Ensures efficient performance for backhaul and enterprise applications.
Installation Process
- Unbox and Inspect: Verify all components, including the device, mounting brackets, and cables.
- Mounting – Install the unit on a stable pole or structure. Ensure it is securely fastened.
- Connect Power – Use the included PoE adapter to power the device.
- Align the Antennas – Use alignment tools to ensure optimal line of sight.
- Configure Settings – Access the device interface via Ethernet to set up the IP, frequency, and other network parameters.
- Test and Optimize – Verify signal strength and throughput to finalize the setup.
How to Use:
- Login to Device Interface – Access via default IP through a connected laptop or PC.
- Configure Network – Set up IP addresses, subnet masks, and throughput parameters.
- Monitor and Maintain -Regularly check the dashboard for performance metrics and firmware updates.
FAQs
What is the maximum throughput of the airFiber 24 Hi-Density?
The airFiber 24 Hi-Density supports a maximum throughput of 2Gbps, ensuring high-speed and reliable wireless connectivity.
What is the range of the airFiber 24 Hi-Density?
The device can maintain a stable connection over a range of up to 20 kilometers under optimal conditions.
Is the airFiber 24 Hi-Density weatherproof?
Yes, the device is designed with a rugged, weatherproof enclosure to perform in extreme weather conditions, from -40°C to 55°C (-40°F to 131°F).
What kind of encryption does the airFiber 24 Hi-Density use?
It uses 128-bit AES encryption, ensuring secure data transmission across the network.
What power supply is required to operate the device?
The airFiber 24 Hi-Density comes with a 50V, 1.2A PoE GigE adapter, which is included in the package.
Can this device be used in urban environments?
Yes, the airFiber 24 Hi-Density is suitable for urban and rural environments, providing low-latency and high-speed connectivity even in challenging scenarios.
